BEFANBY is able to manufacture battery powered transfer car
Xinxiang Hundred Percent Electrical and Mechanical Co., Ltd, the leading manufacturer and No.1 brands of cross-bay transfer system in China, is dedicated to the dseveloping, manufacturing, marketing and service of the cross-bay material transfer system.
The BEFANBY is able to manufacture low-voltage rail powered transfer car system, cable drum transfer equipment, shrouded busbar transfer vehicle, transfer cart battery operated, cable powered rail trolley and manually operate trolley with capacity up to 300 tons. The annual production capacity is over 500 sets. The company owns more than 2 utility-model patents of cross-bay transfer system, including the design of turning transfer car running on S or U shaped rail tracks, 50t steerable transfer cart on cement with 360 degree turn and the design of 3 layer transfer car in vacuum furnace, etc.
Battery powered transfer car Features
- Anti-explosion,Anti-high temperature;
- With lifting holes, convenient to shipment;
- Storage battery powered;
- Stable start, big starting power, long lifetime;
- Safety and flexible;
- no strict requirement for the construction of the railway;
- No limit of running distance;
- Safe and convenient operation for there is no wire outside the car;
- Adjustable speed;
- Large load capacity(1-300t).
Battery powered transfer car Application
The Steel plant battery operated rail transfer cart is suitable for various industries, steel mill, transfer steel products such as steel structure, steel pipe, steel billets, steel ladle and coil, etc from one location to another; Paper roll plant: transfer paper coil Painting shops: transfer workpiece into the painting room Sand blasting room Other industries: shipbuilding, quarries, warehouses and multi-bay workshops, etc
Battery powered transfer car Working principle
The kpx series transfer car is powered by the battery. Battery supplies electricity to the DC motor which is controlled by the electrical control system installed on the car. DC motor drives the car to start, stop, go forward and backward and adjust its speed. And also, the speed of the transfer car is adjustable. Different battery voltages are designed according to the cart frame structure and its load capacity.
Battery powered transfer car Basic item
| Model | KPX-2t | KPX-20t | KPX-50t | KPX-100t | KPX-150t |
| Rated Load(t) | 2 | 20 | 50 | 100 | 150 |
| TableSize(mm) | Length(L) | 2000 | 4000 | 5500 | 6500 | 10000 |
| Width(W) | 1500 | 2000 | 2500 | 2800 | 3000 |
| Heigth(H) | 450 | 550 | 650 | 850 | 1200 |
| Wheel Base(mm) | 1200 | 2800 | 4200 | 4900 | 7000 |
| Rail Inner Gauge(mm) | 1200 | 1435 | 1435 | 2000 | 2000 |
| Wheel Diameter(mm) | 270 | 350 | 500 | 600 | 600 |
| Wheel Quantity | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance(mm) | 50 | 50 | 50 | 75 | 75 |
| Running Speed(mm) | 25 | 20 | 20 | 20 | 18 |
| Motor Power(kw) | 0.8 | 2.5 | 5.5 | 11 | 15 |
| Max Wheel Load(KN) | 14.4 | 77.7 | 174 | 343.8 | 265.2 |
| Reference Weight(t) | 2.3 | 5.5 | 7.6 | 13.9 | 26 |
| Recommended Rail Model | P15 | P24 | P43 | QU100 | QU100 |
Customized:
load capacity, table size, and rail gauge can be customized
opinions:
1>remote radio control(import or made in china) Automatic stop when detecting obstacle or person, limit switches(to limite travel)
2>Battery type (Free of maintenance Battery, lithium battery, explosion-proof battery, and anti-high temperature battery)
3>motor(DC motor with brush and DC motor brushless
4> Electrical parts (imported or made in china)
About Us
Our philosophy: Make friends by integrity, expand business by sincerity, realize win win by development.
make with care, improve with perseverance, serve with heart, achieve satisfaction.
The BEFANBY is committed to be the NO. 1 cross-bay transfer system around the world.
History
Established in the September of 2003, BEFANBY is located within Xinxiang City, which is the cradle of heavy machinery in China. The company occupies 35,000 square meters, owns over 100 staff, and includes the production department, R & D department, marketing department, international marketing department, quality control team and after-sales service etc.
With complete mainland marketing networks and after-sales service channels, the business have covers every province, autonomous regions and municipalities in China. In 2008, the BEFANBY set up the international marketing department and began to open the oversea markets, after 6-years manage improvement and rapid development, the products have been exported to over 30 countries and regions, such as US, Germany, Netherlands, Australia, United Arab Emirate, Saudi Arabia, Mexico, Brazil and Argentina as well as the south-east Asia, etc.
Client visit
Support
BEFANBY
There are 3 senior engineers and 6 engineers owning the middle-level titles and 10 senior technicians in the R & D department. The R & D department cooperate and communicate with the Nanjing Engineering University all the year round, and in order to guarantee the craft, quality and production (efficiency) of the transfer system on rail, we also invited the experienced welding technician to guide the welding and train our staff at site. Meanwhile, the BEFANBY is capable of realizing the customization and manufacture of non-standard transfer system, such as, high temperature, anti-explosive, anti-dust working environment or special material transfer system etc.
After-sales
1>. Our commitment: The load bearing safety factor of the trolley is no less than 120%.
2>.Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.
3>. 16 hours engineering service and 24 hours internet service for our customers.
4>. During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.
5>. Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
